Description
Model-specific values
| Parameter | H3K-HS | H3K6-HS | H4K-HS | H4K6-HS | H5K-HS | H6K-HS | H8K-HS |
|---|---|---|---|---|---|---|---|
| PV Input | |||||||
| Max. Array Power | 6,000W | 7,200W | 8,000W | 9,200W | 10,000W | 12,000W | 1,6000W* |
| Max. Input Power | 3,000W / 1,800W | 3,600W / 2,160W | 4,000W / 2,400W | 4,600W / 2,760W | 5,000W / 3,000W | 5,000W / 4,600W | 6,400W / 6,400W |
| AC Input / Output | |||||||
| Nominal Power | 3,000W | 3,600W | 4,000W | 4,600W | 5,000W | 6,000W | 8,000W |
| Max. Apparent Power | 3,300VA | 4,000VA | 4,400VA | 5,060VA | 5,500VA | 6,600VA | 8,800VA |
| Nominal Current | 13.6A | 16.3A | 18.1A | 20.9A | 22.7A | 27.2A | 36.3A |
| Max. Current | 15.0A | 18.0A | 20.0A | 23.0A | 25.0A | 30.0A | 40.0A |
| Back-Up (AC Output) | |||||||
| Nominal Output Power | 3,000VA | 3,600VA | 4,000VA | 4,600VA | 5,000VA | 6,000VA | 8,000VA |
| Max. Continues Output Apparent Power | 3,300VA | 4,000VA | 4,400VA | 5,060VA | 5,500VA | 6,600VA | 8,000VA |
| Peak Output Power | 4,500W; 10s | 5,400W; 10s | 6,000W; 10s | 6,900W; 10s | 7,500W; 10s | 9,000W; 10s | 9600W; 10s |
| Max. Output Current | 15.0A | 18.0A | 20.0A | 23.0A | 25.0A | 30.0A | 36.3A |
Values common to all models
PV Input
- Max. Input Voltage: 600V
- Start-up Voltage: 50V
- MPPT Operating Voltage Range: 80 – 560V
- Max. Input Current: 32A (16 / 16)
- Max. Short-circuit Current: 48A (24 / 24)
- Number of MPPTs: 2
- PV input number (Number of String Per MPPT): 2 (1 / 1)
AC Input / Output
- Nominal Voltage: 1 / N / PE, 220 / 230 / 240V
- AC Voltage Range: 154 ~ 276V
- THDi: < 3%
- Frequency: 50 / 45-55Hz; 60 / 55-65Hz
- Adjustable Power Factor: 0.8 leading…0.8 lagging
- DC Current Injection: < 0.5% In
Back-Up (AC Output)
- Switch Time: < 10ms
Battery
- Battery Type: LiFePO4
- Battery Voltage Range: 80 – 490V
- Max. Charge/Discharge Current: 35A
- Max. Charge/Discharge Power: 8,000W
Efficiency
- Max. Efficiency: 98.60%
- European Weighted Efficiency: 98.20%
- MPPT Efficiency: 99.90%
- Battery Charge/Discharge Efficiency: 97.50%
Protection
- DC Insulation Resistance Detection: Yes
- Residual Current Monitoring: Yes
- DC Reverse Polarity Protection: Yes
- DC/AC Surge Protection: Type II
- DC Switch: Yes
- Anti-islanding Protection: Yes
- AC Over Current Protection: Yes
- AC Short-circuit Protection: Yes
- AC Over Voltage Protection: Yes
- Grounded Fault Detection: Yes
General Data
- Operating Temperature Range: -25 to +60°C
- Relative Operating Humidity: 0 – 100 %RH
- Max. Operating Altitude: 4,000m
- Cooling: Natural Cooling
- Display: LED / App / Web
- Communication: CAN / RS485 / WIFI / 4G / LAN
- Weight: 20kg
- Dimensions (W*H*D): 522*416*177.6mm
- Degree of Protection: IP65
- Mounting: Wall Mounted
