Description
PP-S2 Technical Specifications
Model-specific values
| Parameter | SIA-3.6kW | SIA-4.6kW¹ | SIA-5kW | SIA-6kW | SIA-8kW | SIA-10kW |
|---|---|---|---|---|---|---|
| PV Input | ||||||
| Max. PV Input Power | 7360 Wp | 9200 Wp | 10000 Wp | 12000 Wp | 16000 Wp | 20000 Wp |
| Max. Input Current | 32 A (16 A * 2) | 32 A (16 A * 2) | 32 A (16 A * 2) | 32 A (16 A * 2) | 64 A (32 A * 2) | 64 A (32 A * 2) |
| Max. Input Short Circuit Current | 44 A (22 A * 2) | 44 A (22 A * 2) | 44 A (22 A * 2) | 44 A (22 A * 2) | 88 A (44A * 2) | 88 A (44A * 2) |
| No. of MPPT | 2 | 2 | 2 | 2 | 2 | 2 |
| No. of PV Strings per MPPT | 1 | 1 | 1 | 1 | 2 | 2 |
| AC Input/Output | ||||||
| Rated Input/Output Power | 7360 W / 3680 W | 9200 W / 4600 W | 10000 W / 5000 W | 12000 W / 6000 W | 14490 W / 8000 W | 14490 W / 10000 W |
| Max. Apparent Input/Output Power | 7360 VA / 3680 VA | 9200 VA / 4600 VA | 10000 VA / 5000 VA | 12000 VA / 6000 VA | 14490 VA / 8000 VA | 14490 VA / 10000 VA |
| Rated Input / Output Current | 32 A / 16 A | 40 A / 20 A | 43.5 A / 21.8 A | 52.2 A / 26.1 A | 63 A / 34.8 A | 63 A / 43.5 A |
| Max. Input / Output Current | 32 A / 16 A | 40 A / 20 A | 43.5 A / 21.8 A | 52.2 A / 26.1 A | 63 A / 34.8 A | 63 A / 43.5 A |
| EPS Output | ||||||
| Rated Outpout Power² | 3680 W | 4600 W | 5000 W | 6000 W | 8000 W | 10000 W |
| Peak Apparent Output Power | 1.5 times of rated power, 10s | 1.5 times of rated power, 10s | 1.5 times of rated power, 10s | 1.5 times of rated power, 10s | 1.5 times of rated power, 10s | 14490W, 10S |
| Rated Output Current | 16 A | 20 A | 21.8 A | 26.1 A | 34.8 A | 43.5 A |
Values common to all models
PV Input
- Max. Input Voltage: 600 V
- Rated Input Voltage: 360 V
- Start-up Voltage: 90 V
- MPPT Voltage Range: 50…560 V
Battery Model
- Battery Type: LFP, 3.2 V / 52 Ah
- Battery PACK Configuration: 1P*30S, 4.992 kWh
- Battery Capacity: 4.992…19.968 kWh
- Voltage Range: 80…500 V
- Max. Charging/Discharging Current: 50 / 50 A
AC Input/Output
- Rated Output Voltage: 1/N/PE, 220 V / 230 V / 240 V
- Rated Frequency: 50/60 Hz
- Power Factor: 1 (-0.8…+0.8 adjustable)
- Total Harmonic Distortion (THDi): < 3%
EPS Output
- Rated Output Voltage: 1/N/PE, 220 V / 230 V / 240 V
- Rated Frequency: 50/60 Hz
- Back-up Switch Time: < 10 ms
- Power Factor: 1 (-0.8…+0.8 adjustable)
- Total Harmonic Distortion (THDi): < 2%
Efficiency
- PV Max. Efficiency: 97.80%
- PV Europe Efficiency: 97.30%
Protection
Over/Under Voltage Protection, DC Isolation Protection, DC Injection Monitoring, Residual Current Detection, Anti-islanding Protection, Over LoadProtection, Battery Input Reverse Polarity Protection, PV Reverse Polarity Protection, Surge Protection, Over Heat Protection, AFCI (optional)
General Data
- Topology: Non-isolated
- Dimensions (W*D*H): 600*350*370 mm (Inverter module), 600*350*210 mm (High Voltage Box and Base), 600*350*305 mm (Battery module)
- Weight: 27.4 kg (Inverter module), 11 kg (High Voltage Box and Base), 57 kg (Battery module)
- Operating Temperature Range: -20°C…+55°C³
- Relative Humidity: 0%…95%
- Altitude: ≤3000 m
- Cooling: Natural Convection
- Noise: < 25 dB
- Ingress Protection: IP 65
- Display: LED / APP
- Communication: RS485 / CAN
- Installation: Floor-standing
- Standard⁴: UN 38.3, IEC 61000, IEC 62619, IEC 63056, IEC 62109, IEC 62040, AS/NZS 4777.2, EN 50549-1/-10, G98/G99, CEI 0-21
